Computer Aided Manufacturing

Siemens NX CAM Basics

This seminar covers the functionalities and opportunities provided by the Siemens  NX CAM module in the areas of 3-axis rough machining, 3-axis finishing and simple drilling.
The process-based philosophy and the effective use of the NX CAM module is taught using practical examples.
The integration and consistency of NC machining on NX and in the customer's area of application will also be analysed and established.

  • The NX program package
  • Basics of NX / user interface
  • CAM process based on the Master Model Concept with Wave Technology
  • Basic process from modelling through to production
  • Basic machining of planar surfaces using the Floor Wall module
  • Plane roughing complex geometries using the Cavity Milling module
  • Basic drilling modules (drilling, sinking, reaming, tapping) using the Hole Making module
  • Toolpaths check (verification)
  • Machine control and post-processing
  • 3-axis finishing (Z level, mill contour)

Additional Requirements
General principles of NC programming, participation in the  "NX CAD Basics" seminar, or equivalent NX/CAD training  and NX experience.

Additional information's for the duration
An additional three days of on-site practical application is recommended. Additional days as required.

 5 Days



  • Production engineers
  • NC programmers
  • Production planning

 Required Training
 NX CAD Basics
If you are interested in a company-specific custom development and  would like to find out more, please feel free to get in touch with us.

Give us a call on: +49 (0)  176 310 693 62
or send an email to:

Alternatively,  You can fill out our contact form here. We look forward to hearing from you.
